Wooden folding section loft ladder

Wooden folding section attc ladders

  • LWN


    • Beige hatchbeige hatch - string
    • Treads set flush with ladder stringsnon-slip steps
    • Easy fittingsimple installation
    • Possibility of installing additional accessoriesadditional accessories available
    • 1 year warranty
    LWN
    • 250 lbs maximum loading 3/8 hatch thickness ANSI 14.9.2004 norm requirements

    LWN

    The LWN is a basic, three-section folding attic ladder with a paintable particleboard lid. It is suitable for areas that do not require an insulated attic ladder.



    Click below to enlarge the image.



    LWN

  • LWP


    • Beige hatchbeige hatch - lock
    • Peripheral sealperipheral gasket
    • Treads set flush with ladder stringsnon-slip steps
    • Handrailhandrail
    • Easy fittingsimple installation
    • Possibility of installing additional accessoriesadditional accessories available
    • Fully assembledfully assembled and ready for quick installation in the ceiling
    • 2 year warranty
    LWP INSULATED
    • 300 lbs maximum loading 1 1/8 insulation thickness 1 3/8 hatch thickness ANSI 14.9.2004 norm requirements 5.9 attic ladder R-value

    LWPLWP

    The LWP ladder is made of wood and folds in three sections. The lid is insulated and a seal lines the perimeter of the frame.

    Click below to enlarge the image.

    LWP



  • LWF


    • Stile endsplastic ends
    • Fire - resistant hatchfire-resistant white hatch
    • Three peripheral sealsthree peripheral gaskets
    • Treads set flush with ladder stringsnon-slip steps
    • Handrailhandrail
    • Possibility of installing additional accessoriesadditional accessories available
    • Fully assembledfully assembled and ready for quick installation in the ceiling
    • 2 year warranty
    LWF FIRE RATED
    • 300 lbs maximum loading 2 7/8 insulation thickness 3 1/8 hatch thickness ASTM E119 and NFPA 288 norm requirements 9.5 attic ladder R-value

    LWF

    The LWF is a half-hour fire-rated attic ladder that folds in three sections. A peripheral seal expands under extreme heat, sealing the hatch and fire-free storey.

    Fire-rating, LWF - NFPA 288-12 (USA); CAN/ULC S101-07 (Canada); ASTM E119-14 (Intern’l).

    Click below to enlarge the image.



    LWF





Instructions

 Installation instructions:

 Technical specifications:

 Attic ladder pre-installation guidelines:

 Safety instructions:

 Certificate:
