Balcony window FGH-V

Balcony window

  • An innovative, large roof window that opens into a balcony. The upper sash opens upwards while the lower sash opens forward to create a balcony bay. The window stays open anywhere along the 0 ​​to 45​ ​​​degree opening range.
  • Side safety barriers are integrated into the bottom sash and slide out during opening. When closing the lower sash, balcony rails are hidden inside the window and are not visible above the roof surface. Concealed under the window flashing elements they do not collect dirt or spoil aesthetics of the roof. Once the balcony window is open, barriers are always dry and clean to secure trouble-free operation.
  • The window is operated by the handle located at the bottom of the upper sash which has a two-point locking mechanism.
  • Automatic air inlet V40P adjusts the air pressure in the room to compliment the air pressure outdoors for maximum performance and stability.
  • Both the upper and lower sash are equipped with​ ​laminated​ glazing unit P2.
  • The highest quality pine wood, vacuum impregnated.
  • ​​Double-coated wood with ecological acrylic lacquer​, ​finished in a natural​ ​wood color.
  • Increased resistance to burglary - TopSafe system.
  • A wide range of accessories available.
  • Installation range is 35 to 55 degrees.



Please note, standard glazing units are only suitable for installation of up to 3,000 feet above sea level.

Balcony window FGH-V







FAKRO skylight balcony in ep. 3 of "Instant Dream Home" on Netflix!

Topsafe® system of burglary protection as standard



Topsafe® system of burglary protection as standard







  • FGH-V Galeria


    • Air inlet V40Pautomatic air inlet V40P
    • Glazing unit P2safety glazing unit P2
    • Flashing EHV-AT Thermowide range of accessories
    • Suitable for pitches from 35-55installation range: 35 – 55°
    FGH-V P2 Galeria
    • 0,26 BTU/hft²F (1.5 W/m²K) window U-value 0,18 BTU/hft²F (1.1 W/m²K) glazing U-value 35 dB acoustic insulation Rw 4HS-14-33.2T glazing unit argon inert gas filled panes + external glass toughened + internal glass laminated, anti-burglary glass class P2A V40P air inlet type four seals Elegant handle

FGH-V available sizes

Size EU [cm]
Size US [in]



78 x 255
31 x 101

94 x 255
37 x 101

Rough opening

mm.

in.



800 x 2570

31½ x 101

960 x 2570

37½ x 101

Outside frame

mm.

in.

777 x 2545

30½ x 100⅛

937 x 2545

36⅞ x 100⅛
