Fire-Rated

  • LMF 60


    • Stile endsplastic ends
    • Klapa jednostronnie ognioodpornafire-resistant insulated door with white finish
    • Three peripheral sealsthree weather seal gaskets
    • Non-slip treadsnon-slip metal steps
    • Handrailhandrail (10'1” max. ceiling ladders)
    • Ladder unloading mechanismladder unloading mechanism, built in handrail (only in 11'10" max. ceiling ladders)
    • Possibility of installing additional accessoriesadditional accessories available
    • Do wysokich pomieszczeńintended for installation with high ceilings
    • 2 year warranty
    LMF 60
    • 350 lbs maximum loading 3 1/8 insulation thickness 3 3/8 hatch thickness 60 minutes in accordance with ASTM E119-14 and NFPA 288 norm requirements 8.9 attic ladder R-value

    LMF 60

    The LMF60 model is a new generation attic ladder that provides access to unused space in the attic and at the same time functions as a fire protection for 60 minutes (1 hour rating in accordance with NFPA 288 and ASTM E119-14.)

  • LWF


    • Stile endsplastic ends
    • Klapa jednostronnie ognioodpornafire-resistant insulated door with white finish
    • Three peripheral sealsthree weather seal gaskets
    • Treads set flush with ladder stringsnon-slip steps
    • Handrailhandrail
    • Possibility of installing additional accessoriesadditional accessories available
    • 2 year warranty
    LWF FIRE RATED
    • 350 lbs maximum loading 2 7/8 insulation thickness 3 1/8 hatch thickness 43 min per ASTM E119, 30 min per NFPA 288 norm requirements 9.5 attic ladder R-value

    LWF

    The LWF fire rated ladder provides easy access to an attic while functioning as a blaze block in case of fire. The hatch is manufactured with the use of fireproof materials and is equipped with a gasket that expands under extreme heat. The LWF ladder is fire rated at 43 minutes in accordance with ASTM E119 and 30 minutes in accordance with NFPA 288.

  • LSF


    • Klapa jednostronnie ognioodpornafire-resistant metal door with white finish
    • Listwy wykonczeniowewhite metal trim
    • Metal treadnon-slip steps
    • Additional treadpossibility of adding or detaching steps
    • Ladder lenght adjustingsystem of adopting the ladder length to the ceiling height
    • System of quick installation in the ceilingquick installation in the ceiling - installation brackets
    • Possibility of installing additional accessoriesadditional accessories available
    • 2 year warranty
    LSF FIRE RATED
    • 350 lbs maximum loading 1 1/8 insulation thickness 2 1/8 hatch thickness ČSN 73 0810, El₂ 60 min per EN 13501-2 standard. norm requirements 3.2 attic ladder R-value

    LSF

    The Fakro LSF Metal Attic Ladder is a fire rated and insulated ladder that can serve as a fire block.

    The hatch is manufactured with the use of fireproof materials and is equipped with a gasket that expands under extreme heat.

    The ladder is fully made of metal, it has 9 steps and features a load limit of 350 lb. The LSF ladder is fire-rated at 60 minutes as per ČSN 73 0810.

  • DWF


    • Fully assembled and ready for quick installationready for quick installation
    • Białe skrzydło drzwiowewhite finish
    • Uszczelka obwodowa do drzwi kolankowychweather seal
    • Treads protruding from stringsfire classification as per EN 13501:2 - EI145
    • Do wysokich pomieszczeńUniversal fit(left or right swing)
    • 3 year warranty3 year warranty
    DWF
    • maximum loading 2 3/8 insulation thickness 2 1/2 hatch thickness EN 13501-2 norm requirements 8.9 access door R-value

    DWF

    The DWF fire-rated L-shaped combination door provides access to otherwise unused spaces under closed off stairwells and crawl spaces. It is fi re resistant from both sides at 145 minutes as per EN13501). The white, 2½ inch thick sash is thermally insulated providing an excellent barrier that reduces heat loss (R-value 8.9*). The doors can be installed in two versions of opening (right or left). Includes natural pine-coloured trim.
    * manufacturer’s internal calculations
